THE IDEAL CHIPPER FOR DEMOLITION WORK
Known for their reliability and ease of maintenance, MAC3 chipper are ideal for all demolition jobs.
CHIPPER
HIGHLIGHTS
0% lubricant for operation - optimized use and maintenance
100% user security - pulls out by latch or double threaded screw
30% yield optimization - thanks to the internal manufacturing process
DOCUMENTATION
-
To access more materials, please visit
.
FEATURES
Monobloc cylinder machined in the steel bar
- Limited requested parts
- Better resistance over time
- Optimization performance
Heat treatment
- Mechanical characteristics optimization
- Self-lubrication on operation
Zinc-plated surface treatment
- Better protection against corrosion
Direct strike on air cushion
- Reliability and longevity
- Comfort in use
Easy access to distribution
- Easy maintenance
Double threaded screw retainer
- Quicker tool changes
- Safety for users
APPLICATIONS
FIELDS OF APPLICATION
SPECIFICATIONS
TECHNICAL DATA
| SECURITY* | CLOSING SYSTEM | WEIGHT | LENGTH | CADENCE | AIR CONSUMPTION | SHANK SIZE | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MODEL | kg | Id | mm | In. | bpm | l/min | cfm | Type | mm | in. | ||
| P5 | ○ | Screwed | 5 | 11 | 354 | 13,9 | 2800 | 500 | 17,7 | Hex | 19 x 50 | 3/4" x 2" |
| P5 | ○ | Screwed | 5,1 | 11,3 | 364 | 14,3 | 2800 | 500 | 17,7 | Con | 26/16 x 70 | 5/8" x 2 3/4" |
| P5 | ○ | Screwed | 6,2 | 13,7 | 392 | 15,2 | 2800 | 500 | 17,7 | Rd | 24 x 70 | 15/16" x 2 3/4" |
| P7 | ○ | Screwed | 7 | 15,5 | 437 | 17,2 | 2200 | 900 | 31,8 | Rd | 24 x 70 | 15/16" x 2 3/4" |
| P7 | ○ | Screwed | 6,8 | 15 | 422 | 16,6 | 2200 | 900 | 31,8 | Rd | 23 x 70 | 29/32" x 2 3/4" |
| P7 | ○ | Screwed | 6,8 | 15 | 422 | 16,6 | 2200 | 900 | 31,8 | RdHex | 23 x 70 | 29/32" x 2 3/4" |
| P7 | ○ | Screwed | 7 | 15,5 | 420 | 16,5 | 2200 | 900 | 31,8 | Rd | 19 x 50 | 3/4" x 2" |
○ = in option
* = safety device against unintentional start-up, mandatory in the CE zone
Tools eligible for the PROS MSD prevention program
The P5 & P7 chisels are part of the "TMS Pros" program supported by the French health insurance scheme, and are eligible for simplified funding.
